This is EMRad, a series aimed at providing “just in time” approaches to commonly ordered radiology studies in the emergency department. When applicable, it will provide pertinent measurements specific to management, and offer a framework for when to get an additional view, if appropriate. Last post, we focused on the elbow. Now: the wrist.

Learning Objectives

  1. Interpret traumatic wrist x-rays using a standard approach.
  2. Identify clinical scenarios in which an additional view might improve pathology diagnosis

Why the wrist matters and the radiology rule of 2’s

The Wrist

  • 25% of all sports-related injuries involve the hand or wrist.​1​
  • Approximately 1.5% of all ED visits involve the hand and forearm.​2​
  • Missed wrist injuries can be highly morbid.
  • Missed wrist injuries are a common area of litigation.

Before we begin: Make sure to employ the rule of 2’s​3​

  • 2 views: One view is never enough.
  • 2 abnormalities: If you see one abnormality, look for another.
  • 2 joints: Image above and below (especially for forearm and leg).
  • 2 sides: If unsure regarding a potential pathologic finding, compared to another side.
  • 2 occasions: Always compare with old x-rays if available.
  • 2 visits: Bring the patient back for repeat films.

An approach to the traumatic wrist x-ray

  1. Adequacy/Alignment
  2. Bones
    1. Distal radius
    2. Distal ulna
    3. Carpal bones
  3. Carpal/metacarpal alignment
    1. Perilunate/lunate dislocation
    2. Gilula’s Lines
    3. Carpometacarpal dislocation
    4. Distal radioulnar joint (DRUJ) subluxation/dislocation
  4. Consider an additional view

1. Adequacy

  • PA View
    • Check for rotation. There should be no overlap of radius and ulna.
    • The view should include distal radius and ulna.
Figure 1: Anteroposterior x-ray of normal wrist. Case courtesy of Dr. Jeremy Jones. Radiopaedia.org. Annotations by Stephen Villa, MD.
  • Lateral View
    • Check for rotation. There should be a perfect overlap of radius and ulna.
    • Identify the distal radius, lunate and capitate. They should make a straight line.
Figure 2: Lateral x-ray of wrist demonstrating normal alignment. Case courtesy of Dr. Jeremy Jones. Radiopaedia.org. Annotations by Stephen Villa, MD.

2. Bones

  • Distal radius and ulnar styloid
    • On the AP view, the distal radius should cup the carpals and the most distal portion of the articular surface should be radial styloid (radiocarpal joint).
    • On the lateral view, the radial surface should be smooth. If it is not, consider possible distal radius fracture.
    • Trace the ulnar styloid: If it is not, interrogate the ulna for a possible fracture.
      • Pearl: This injury is usually not isolated, so look carefully for a second fracture.
  • Carpal Bones
    • Trace cortex of all carpal bones.
    • Look specifically at the scaphoid. If there is a high suspicion for injury, consider scaphoid view/series.
Figure 4: Illustrated carpal bones. Case courtesy of Dr Phillip Marsh, Radiopaedia.org, Red = Scaphoid, Pink = Lunate, Orange = Triquetral, Purple = Pisiform, Light Blue = Trapezium, Yellow = Trapezoid, Green = Capitate, Dark Blue = Hamate, Black = Hook of the hamate

3. Carpal/Metacarpal and Joint Alignment

Figure 4: Lateral x-ray of wrist demonstrating expected alignment. Case courtesy of Dr. Jeremy Jones. Radiopaedia.org. Annotations by Stephen Villa, MD.
  • AP view
    • Carpal bones are arranged in 2 rows forming 3 smooth arcs (Gilula’s arcs) and separated by 1-2 mm space. If there is a break in the arc, think carpal bone fracture or ligamentous injury.
    • Look specifically at scaphoid and lunate for widening. If widening is present, think scapholunate dissociation and consider obtaining a  “clenched fist” view.
Figure 5: AP X-ray representation of Gilula lines. Case courtesy of Dr Benoudina Samir, Radiopaedia.org

On AP and Lateral, the joint space between distal row and carpals should be visible. If it is not, think carpometacarpal dislocation. Sometimes, this dislocation is easiest to see on lateral (see Figure 7).

Figure 7: Lateral view of wrist demonstrating a carpometacarpal dislocation. Case courtesy of A.Prof Frank Gaillard, Radiopaedia.org.

4. Consider an Additional View

Scaphoid view or series

  • When: High suspicion for scaphoid fracture
  • Why: Obtaining the film with the patient in ulnar deviation should make the scaphoid easier to see.
Figure 9: Scaphoid view of wrist. Patient is in ulnar deviation and the scaphoid is more clearly depicted. Case courtesy of Dr Maulik S Patel, Radiopaedia.org.

The “clenched fist” view

Figure 10: Scapholunate dissociation of right hand. Case courtesy of Andrew Murphy, Radiopaedia.org.

“Carpal tunnel” view

  • When: Consider this view when a patient has pain at hypothenar eminence or a sensory deficit in the ulnar distribution.
  • Why: If fractured, the hook of hamate can displace into Guyon’s Canal causing ulnar nerve sensory changes.
Figure 11: A) Graphic of carpal tunnel view. B) Carpal tunnel view. Cases courtesy of Dr Behrang Amini, Radiopaedia.org, and Dr Maulik S Patel, Radiopaedia.org

Read more about positive findings in our SplintER Series: Common ED Splint Techniques.
Afraid you might miss something commonly missed or catastrophic? Can’t Miss wrist injuries.
Want a more in-depth approach to wrist radiography? Check out radiopaedia’s approach to the wrist.
